| Lens |
Standard 24°, Wide-angle 47°, Macro 50μm
|
| IR Resolution |
384 x 288 px
|
| Field of View (FOV) |
28° x 21°
|
| Thermal Sensitivity (NETD) |
≤ 0,06 °C at 30 °C
|
| Spatial Resolution (IFOV) |
1,27 mrad
|
| Digital zoom |
1 – 8 x
|
| Detector Type |
Focal Plane Array (FPA) Focal Plane Array (FPA) uncooled microbolometer
|
| Spectral Range |
8 – 14 μm
|
| Minimum Focus Length |
0,15 m
|
| Focus |
Manual
|
| Temperature Range |
-20 °C – 650 °C
|
| Measurement Accuracy |
± 2 °C or ± 2 %, whichever is greater (ambient temperature between 15 °C – 35 °C)
|
| Automatic Capture of High and Low Temperature |
Automatic marking of hot or cold spots within the measurement area
|
| Region of Interest - Measurement Modes |
8 moveable spots, 8 moveable area boxes (max. / min.), 1 line (max. / min.)
|
| Correction Settings |
Emissivity, reflected background temperature, relative humidity, ambient temperature, measuring distance, transmission
|
