| Lens |
Standard 25°, Wide-angle 44°, Telephoto 12°, Ultra-Telephoto 7°
|
| IR Resolution |
640 × 480 px or SuperResolution 1280 × 960 px
|
| Field of View (FOV) |
25° × 19°
|
| Thermal Sensitivity (NETD) |
＜0.04 °C at 30 °C
|
| Spatial Resolution (IFOV) |
0,68 mrad
|
| Digital zoom |
1 – 8 x
|
| Detector Type |
Focal Plane Array (FPA) Focal Plane Array (FPA) uncooled microbolometer
|
| Spectral Range |
7 – 14 μm
|
| Minimum Focus Length |
0,25 m
|
| Focus |
TurboFocus (fast, intelligent Autofocus system for continuously sharp images), laser distance, graphic contrast, manual
|
| Temperature Measurement Range |
-20 °C to 150 °C, 0 °C to 650 °C, 200 °C to 1200 °C
|
| Measurement Accuracy |
± 2 °C or ± 2 %, whichever is greater (ambient temperature between 15 °C – 35 °C)
|
| Automatic Capture of High and Low Temperature |
Automatic full-screen and measurement boxes both with highest / lowest temp spot marker
|
| Region of Interest - Measurement Modes |
8 spot markers, 8 boxes (rectangle or circle), 8 lines
|
| Correction Settings |
Emissivity, Partially emissivity, Reflection temperature, Ambient temperature, Humidity, Distance
|
