| General Specifications |
| Temperature range |
-18 °C … +400 °C |
| Display resolution |
0.2 °C |
Accuracy
(23 °C) |
-18 °C … -1 °C ±3 °C,
-1 °C … +400 °C ±2 % or
±2 °C of reading - whichever is greater |
| Repeatability |
±2 % of reading or ±2 °C - whichever is greater |
| Response time (95%) |
500 msec |
| Emissivity |
preset 0.95 |
| Optics D/L |
=1/8 |
| Spectral response |
7 µm - 18 µm |
| Laser class |
Class 2 |
| Humidity |
10 to 95% r.H.
(non condensing at up to 30 °C (86 °F)) |
| Ambient temperature |
±0 °C … +50 °C (+32 °F … +122 °F) |
| Storage temperature |
-20 °C … +65 °C (-4 °F … +149 °F)
without battery |
| Power supply |
1x IEC 6LR61 (type approved) |
| Dimensions |
152 mm x 101 mm x 38 mm
(~ 6" x 4" x 1.5") |
| Weight |
approx. 200 g (~ 7.1 oz) |
| Art. No. |
AS001120 |
