Parameter index:
Range
(0~10...25...40...60...100...250...400...600)kPa,(0~1...1.6) MPa
Overload pressure
diaphragm differential pressure 200% (positive overpressure); 100% (negative overvoltage)
Backlight color
white backlight
Dial size
80mm
Accuracy level
0.4% FS
Long-term stability
typical: ± 0.2% FS / year
Working temperature
-20 ~ 85 ° C
Compensation temperature
0 ~ 40 °C
Electrical protection
anti-electromagnetic interference design
Sampling frequency
3 times / sec
Measuring medium
gas or liquid compatible with 316 stainless steel
Pressure interface:
G1/4 internal thread
Connector material
304 stainless steel
Shell material
Product function
power on/off backlight back to zero unit switching maximum value minimum record
Supply voltage
3V
Battery display
four-segment display
