| Size |
φ100
φ150 |
| Shape of casing |
Standard case, Closed case
Type A/Type B/Type D |
| Connecting thread |
φ100…G3/8 (G1/2)
φ150…G3/8 (G1/2) |
| Material for the parts touching liquid |
(differs according to pressure)
*General Use
socket:C3604BD, YBSC3
bourdon tube:C2700T, SCM435,
SUS316
*Corrosion Resistant application
socket:SUS316
bourdon:SUS316 |
| Pressure range |
Pressure gauge
0～40MPa（0～400kg/c㎡）
Vacuum gauge
-0.1～0MPa（76cmHg～0cmHg）
Compound gauge
-0.1～2.5MPa（76cmHg～25kg/c㎡） |
| Contacts and electric rating |
Micro-switch（YEC-M）
（Electric rating:AC250V,5A or DC125V,0.4A）
Contact switch（YEC-C）
（Electric rating:AC100V,0.5A or AC200V,0.2A） |
| Operating system |
Upper limit system
Lower limit system
Upper and lower limits system
Center connection system (only for micro-switch) |
