Pressure Range
|
0 ~ 15 kPa ... 150 MPa (Gauge) / 0 ~ 100 kPa ... 7 MPa (Absolute)
-100 kPa ~ 100 ... 3.5 MPa (Compound Gauge)
|
|
Accuracy
|
±0.025% F.S (Gauge)
±0.05% F.S (Absolute, Compound)
** Included Nonlinearity, Hysteresis, Repeatability, errors for -10 ~ 50 ℃ Temperature range
|
|
Over Pressure limit
|
150 % of full scale
|
|
Bust Pressure
|
200 % of full scale, 150 MPa range is 200 MPa
|
|
Pressure Unit
|
kPa, MPa, kgf/cm2, psi, mbar, bar, inHg, inH2O, mmH2O, mmHg
|
|
Workable Temperature Range
|
-20 ~ 70 ℃
|
|
Storage Temperature Range
|
-30 ~ 80 ℃
|
|
Temperature Compensated Range
|
-10 ~ 50 ℃
|
|
RS232 Communication
|
Provided Commands in manual, Available to use private communication cable (Option)
|
