| Pressure medium |
Non-corrosive gases / liquids |
| Pressure reference |
Gauge / Absolute |
| Pressure range |
-100~100 kPa,-100~1000 kPa,0~100 kPa (abs) |
| Power |
10.8~30 VDC |
| Output |
2 switch output (NPN/PNP open collector) and 1~5 VDC analog output |
| Pressure port |
R 1/4,G 3/8,G 1/4,9/16-18UNF |
| Accuracy |
Analog output: ± 3 %FS,Switch output: ± 3 %FS |
| Display |
Full 3-digit LED |
| Ingress Protection |
IEC IP65 |
| Approval |
UL recognized,CE marking applicable |
