| Operating Principle |
Rectifier type |
| Class |
JIS C 1102 : 1997 Class 0.5 |
| Operating Position |
Horizontal |
| Scale Length |
Approximately 135 mm (Deflection Angle: 85°) |
| Scale Divisions |
150 |
| Max. Scale Value |
30/75/150/300 V |
| Rated Accuracy |
± 0.5% between 45 Hz and 10kHz |
| Approximate Consumed Current |
1 mV (1000 Ω/V) |
| Operating Temperature Range |
0 ~ 40 ºC |
| Operating Humidity Range |
30 ~ 75% RH |
| Storage Temperature Range |
-10 ~ 50 ºC |
| Storage Humidity Range |
25 ~ 80% RH |
| Approx. External Dimension |
197 x 181 x 92 mm |
| Approx. External Weight |
1.8 kg |
| Optional Accessories |
2291 01 Carrying case |
| Features |
- Taut-band suspension system eliminates friction and provides good resistance to shock impact.
- For measurements from 45 Hz to 10 kHz with 100Ω/V internal resistance
|
