Medium Conductivity:
|
≥ 5 µS/cm (Liquids or mixture)
|
|
Media Temperature:
|
≦80℃ (Polyurethane), ≦120℃ (Neoprene), ≦150℃ (PFA), ≦150℃ (PTFE)
|
|
Ambient Temperature:
|
-20°C ~ 55°C
|
|
Sensor Size:
|
DN15mm ~ DN200 mm
|
|
Accuracy:
|
±0.5% or 1.0% of reading (Velocity>=0.5m/s), ±0.005m/s (Velocity < 0.5m/s)
|
|
Material of Sensor:
|
Measuring Tube - Stainless Steel 304; Coil - Copper; Sensor housing - Carbon steel or Stainless steel 304
|
|
Liner Material:
|
PTFE, Neoprene, PFA, F46, PU
|
|
Electrode &Grounding:
|
Stainless Steel 316L, Hastelloy B, Hastelloy C, Titanium, Tantalum, Tungsten carbide
|
|
Process Connections:
|
Tri-clamp, hygienic quick connection
|
|
Installation Types:
|
In-line with remote convertor
|
|
Protection:
|
IP 65, IP67 or IP 68 (Submersible, with remote style)
|
|
Power Requirements:
|
110-240 VAC or 16-36 VDC
|
|
Outputs:
|
4-20mA, pulse
|
|
Communication:
|
HART, RS485/Modbus, Profibus-DP
|
