Main specification for liquid
DN4mm-DN500mm
Medium
Liquid
Accuracy
1.0% ,0.5% ,0.2%
Connect
Thread(DN4mm~DN40mm)
Flange(DN10mm~DN500mm)
Pressure
PN0.6 ~ PN16MPa
Medium Temperature
≤120℃
Ambient Temperature
-25℃~60℃
Power Supply
+24VDC
+12VDC~+30VDC
3.6V Lithium battery
Output
Pulse
4 ~ 20mA
RS485
Flange Material
304 Stainless steel
Carbon steel
Body Material
Display
LCD back light display.
Explosion Proof
Exia II CT4 ~ T6, Exd II BT4 ~ T6
