Đồng hồ hiển thị áp suất VWM8C Valcom

Mã sản phẩm: VWM8C |
Thương hiệu:
Giá gốc:

Giá khuyến mại: Liên hệ ( Đã có VAT )

Tiết kiệm: (0%)
Đồng hồ hiển thị áp suất
Model: VWM8C
Hãng: Valcom

    Yêu cầu giá tốt:

    0984.843.683.

    Email: info@ttech.vn

Thông tin sản phẩm
- Can be connected to CC-Link directly. (CC-Link interface included as standard.)
- Simplified design with focus on connection with PLC.
- High speed (100 times/s) and high accuracy.
- Lightweight and compact body. Suitable to be embedded in control panel.
- Dust- and waterproof display (when panel mounted).
- Up to 42 slave units can be connected to one master unit. (Use as a remote device station)


Applicable Sensor Various strain gauge load cell
Loadcell Power Supply DC5V±50±5% 120mA
Measuring Range ±7mV/V
Span Adjustable Range ±7mV/V
Zero Point Adjustment Range ±7mV/V
Display Setting Range ±999.999
Minimum Input Range 0.15µV/d (d = Minimum scale value)
A/D Conversion Method Delta-Sigma method
Sampling speed 100 times/sec.
Accuracy (*1) 0.005% of F.S.
Temperature Characteristic Zero: ±0.02µV/°C(Typ.)±0.1µV/°C(Max.)
Span: ±3ppm/°C(Typ.)±15ppm/°C(Max.)
Display 7 segments Green LED6 digit(Character height: 14.6mm)
Polarity Display: Green LED (×1), Status indication: Red LED (×6)
Display alternates between NET and GROSS weight.
