| Measuring Range |
DC Voltage:320mV/3.2V/32V/320V/500V
AC Voltage:3.2V/32V/320V/500V
Resistance:320Ω/3.2kΩ/32kV/320kV/3.2MΩ/32MΩ
Diode Test:3.2V
Continuity Check:320Ω |
| Display |
3 1/2 digit LCD, max. reading of 3200 |
| Polarity |
Automatic (-)negative indication |
| Over range indication |
”OL” mark on LCD |
| Low battery indication |
"B" mark on LCD |
| Sampling |
2 times/sec |
| Auto power off |
Approx. 10minutes after the power switch on |
| Operating temperature |
0℃ to 40℃,<70% RH (Non-condensing) |
| Storage temperature |
-20℃ to 60℃,<80%RH (Non-condensing) |
| Power supply |
LR-44 (1.55V)×2 |
| Power consumption |
5.0mW |
| Size |
W60×H110×D9.5mm |
| Weight |
Approx. 86g (Including batteries and case) |
| Accessories |
Hard cover case:1
Instruction manual:1
Batteries:2
|
