Thông tin sản phẩm
- Detects one to four gases including H2S, O2, LEL, CO, SO2 and NO2
- Transmits gas level and alarm information over a Wi-Fi network
- Sends an alert to the control room if the worker activates the instrument's panic button or if lack of motion is detected
- Enables a worker's location to be pinpointed in real time at a central console
- Operates on iNet - Industrial Scientific's unique Gas Detection as a Service solution
Thông số kỹ thuật
- Case Material:
Polycarbonate with Protective Rubber Overmold
- Dimensions:
133mm x 73mm x 56mm (5.24" x 2.87" x 2.2")
- Weight:
256 g (9 oz) - Ventis LS, Lithium-ion Battery Version (typical)
304 g (10.7 oz) - Ventis LS Extended Lithium-ion Battery Version (typical)
- Operating Temperature Range:
-20°C- 50°C (-4°F-122°F) typical
- Operating Humidity Range:
15%-95% Non-condensing (continuous) typical
- Display/Readout:
Backlit Liquid Crystal Display (LCD)
- Power Source/Run Time:
Rechargeable Lithium-ion Battery Pack
(12 hours typical @ 20ºC) - Ventis LS
Rechargeable Extended-Range Lithium-ion Battery Pack
(20 hours typical @ 20ºC) - Ventis LS
- Panic and Man Down Alarm :
Panic alarm - triggered by user surpressing red panic button
Man down alarm - triggered by lack of motion at user - defined interval.
Local alarm with ultra-bright LEDs, loud audible alarm (95dB at 30cm) and vibrating alarm.
Remote alarm via WiFi to central console
- Wireless
Remote gas readings
- Sensors:
Combustible gases/methane - Catalytic Diffusion
O2, CO, H2S, NO2, SO2 - Electrochemical
