Optical system
|
Finity optical system/Infinity optical system
|
Observation tubes
|
30°gemel digital viewing head, 3.2 million pixels high resolution camera system:resolution ratio 2048*1536 pixels ,line by line scan
|
Automatic exposure and white balance function.USB2.0 digital output. Display 90% image from field of view
|
Eyepiece
|
PL10X/18mm, High eyepoint, widefield plan eyepiece
|
PL10X/20mm, High eyepoint, widefield plan eyepiece |
Objective
|
Finity high contrast achromatic objective:4X、10X、40XS、100XSO
|
Finity plan achromatic objective:4X、10X、20X、40XS、100XSO |
Infinity plan achromatic objective: 4X、10X、20X、40XS、100XSO |
Nosepiece
|
Quadruple/quintuple with click stop
|
Focusing adjustment
|
Coaxial coarse and fine focusing adjustment, with limited and tension adjustment, coarse adjustment range: 28mm,fine adjustment precision:0.002mm
|
Stage
|
Low position coaxial mechanical stage,size:140x132mm travel range:76x50mm
|
Low position coaxial mechanical stage, size: 150x140mm travel range:76x50mm ,with two sets clips |
Condenser system
|
Critical illumination, rack & Pinion focusable 1.25NA Condenser, fixed center
|
Koehler illumination, rack & Pinion focusable 1.25NA Condenser, adjustable center |
Illuminator
|
Variable voltage 90V~240V,halogen 6V/20W with intensity control
|
Variable voltage 90V~240V, 3W LED lamp with intensity control |
Photography adapter
|
3.2x photo eyepiece ,photo tube(with PK mount)
|
Video adapter
|
0.35X CTV/0.5X CTV/1.0X CTV
|
Other options
|
Phase contrast sliders for condenser(use with phase contrast objective)
|
Dark field slider for condenser |
Simple polarization (with analyser and polarizer) |
