Optical system
|
Infinity color corrected optical system
|
|
Viewing head
|
Main head: 30° inclined trinouclar viewing head,interpupillary distance: 50mm-76mm.splitting ratio binocular: trinocular=100:0/20:80/0:100.
|
| Sub head: 30° inclined binocular viewing head, interpupillary distance: 54mm-75mm. |
| 5-35° tilting trinocular head, interpupillary distance: 50mm-76mm. splitting ratio binocular: trinocular=50:50/100:0/0:100 |
|
Eyepiece
|
High eye-point wide field plan eyepiece PLN10X/22mm, diopter adjustable.
|
| High eye-point wide field plan eyepiece PLN10X/22mm with stop screw,diopter adjustable. |
|
Objective
|
Infinity plan semi apochromatic fluorescent objectives 4X/10X/20X/40X/100X
|
| Universal plan semi-apochromatic objectives 2X/4X/10X/20X/40X/60X/100X |
| Universal plan semi-apochromatic phase contrast objectives 4X/10X/20X/40X/60X/100X |
|
Nosepiece
|
Quintuple nosepiece with DIC slot
|
| Sextuple nosepiece with DIC slot |
| Septuple nosepiece with DIC slot |
|
Middle module
|
Middle module with LED cursor, three colors red/green/blue for option, intensity adjustable.
|
|
Frame
|
Biological transmitted frame, with low-hand coaxial focusing system with upper limit and tension adjustment; coarse range: 25mm, fine precision: 0.001mm.Built-in 100V-240V wide range voltage, with digital dimming and intensity set & reset; built-in LBD/ND6/ND25 filters
|
|
Stage
|
187mm X 166mm double layers mechanical stage, moving range: 80mm X 55mm, precision: 0.1mm;two ways wire slide rail,knob tension adjustable.
|
|
Condenser
|
Swing-out achromatic condenser, N.A.0.9
|
| Universal condenser |
|
Illumination
|
12V/100W halogen, bulb center preset, intensity adjustable
|
|
Camera adapter
|
0.5X, 0.65X, 1X focusing C-mount
|
|
Other accessory
|
External transformer, High precision micrometer
|
