| Nosepiece |
Reversed quintuple nosepiece
|
|
Focus Adjustment
|
Transmitted & Reflected frame, coaxial focus system with tension adjustment and up-limited device, coarse range: 28mm, fine precision: 0.002mm. Stage can be adjusted up and down, 28mm high sample is available.
|
| Reflected frame, coaxial focus system with tension adjustment and up-limited device, coarse range: 28mm, fine precision: 0.002mm. Stage can be adjusted up and down, 78mm high sample is available. |
| Stage |
Double layer mechanical stage with X/Y coaxial adjustment, size: 175mmX145mm, moving range: 76mmX42mm.
|
| Metal plate for transmitted frame; glass plate for transmitted & reflected frame. |
|
Reflected illumination
|
Wide-range voltage 100V-240V_AC50/60Hz, reflected lamp-house with single 5W LED, warm color. Koehler illuminator with oblique light device, center adjustable field and aperture diaphragm
|
| Transmitted illumination |
Wide-range voltage 100V-240V_AC50/60Hz, transmitted lamp-house with single 5W LED, warm color.
|
| Condenser |
N.A.0.9 swing-out achromatic condenser for transmitted frame, with center adjustable aperture iris diaphragm.
|
| Other accessories |
Yellow/neutral/IF550/LBD filter for transmitted light
|
| Digital camera adapter: 1X, 0.67X, 0.5X focusing C-mount, 3.2X photo eyepiece, photo tube with PK or MD mount, relay lens |
| Interference filter for reflected light: Blue filter <=480nm Green filter 520nm~570nm Red filter 630~750nm White balance filter |
| High precision micrometer, scale value 0.01mm |
