| Optical system |
Infinity color corrected optical system |
| Viewing head |
Erect image, 30° inclined gemel trinocular head, interpupillary distance: 50mm~76mm; splitting ratio R: T=100:0 or 0:100 |
| |
Inverted image, 30° inclined gemel trinocular head, interpupillary distance: 50mm~76mm; splitting ratio R:T=100:0 or 20:80 or 0:100 |
| Eyepiece |
High eyepoint wide field plan eyepiece PL10X25mm, diopter adjustable |
| High eyepoint wide field plan eyepiece PL10X25mm, with reticle, diopter adjustable |
| High eyepoint wide field plan eyepiece PL10X26.5mm, diopter adjustable |
| High eyepoint wide field plan eyepiece PL10X26.5mm, with reticle, diopter adjustable |
| Objective |
BD semi-apochromatic metallurgical objectives (5X/10X/20X/50X/100X) |
| Semi-apochromatic metallurgical objectives (5X/10X/20X/50X/100X) |
| Nosepiece (with DIC slot) |
BD quintuple nosepiece, BD sextuple nosepiece |
| Sextuple nosepiece, septuple nosepiece |
Frame
|
Reflected/Transmitted body, low-position coaxial coarse and fine adjustment, coarse adjustment distance: 25mm; fine precision: 0.001mm. With coarse adjustment stop and tightness adjustment. |
| Built-in 100-240V wide voltage transformer, double way power output; intensity adjustable by digital set and reset; switch for reflection and transmission; built-in transmitted filters LBD/ND6/ND25). |
| Reflected body, coaxial coarse and fine adjustment, coarse adjustment distance: 25mm; fine precision: 0.001mm. With coarse adjustment stop and tightness adjustment. |
| Stage |
4 inch three layers mechanical stage with glass plate, moving range: 102mm(Y)*105mm(X) |
| Condenser |
Swing-out type achromatic condenser (N.A.0.9) |
| Reflected illuminator |
BD reflected illuminator with iris field diaphragm and aperture diaphragm, central adjustable. With filter slot and polarizing slot. With switch for bright and dark field |
| lamp house |
12V/100W halogen lamp house, center pre-set |
| Other accessories |
Camera adapter: 0.5X focusing C-mount |
| Fixed polarizer, fixed analyzer, 360° rotatable analyzer |
| DIC attachment |
| Interference filters for reflected light: |
| High precision micrometer, scale value 0.01mm |
