Magnification
|
Standard:10X/30X, using optional eyepiece and auxiliary lens, it can extend to 5X~160X,
|
|
Objective
|
1X、2X、3X、4X
|
|
Eyepiece
|
Wide field and high eyepiont eyepiece WF10X/23mm
|
|
Wide field and high eyepiont eyepiece WF15X/16mm
|
|
Wide field and high eyepiont eyepiece WF20X/12mm
|
|
Viewing Head
|
Binocular head, 45°inclined,360°rotatable, inter-pupillary range 54~76mm, both two side diopter adjustment(±5)
|
|
Trinocular head, fixed light splitting 50% ：50%
|
|
Working Distance
|
Standard:100mm, using optional auxiliary lens can expand to 30mm-165mm
|
|
Auxiliary Lens
|
0.5X/165mm、1.5X/45mm、2X/30mm
|
|
Focus arm
|
tension adjustable, adjust range 50mm
|
|
Stand
|
Pillar type sector stand
|
|
Pillar stand with top & bottom illumination. Bottom illuminator: halogen bulb 12V15W( brightness adjustment )， Oblique lighting 12V/15W
|
|
Pillar stand with top & bottom illumination. Bottom illuminator: fluorescent bulb 230V/8W ， Oblique lighting 12V/15W
|
|
Other type stand, ring light and fluorescent light and fiber light for option.
|
|
Photo device
|
Photo tube（with PK mount），3.2X photo eyepiece
|
|
TV device
|
0.35X/0.5X/1.0X C-mount adapter
|
|
Others
|
Precision measurement platform, dark field condenser, jewelry clip
|
