Model No.
|
260
|
360
|
460
|
|
Vise Travel
|
260mm
|
260mm
|
360mm
|
360mm
|
460mm
|
|
Motor Power
|
3HP
(2300W)
|
5HP
(3800W)
|
5HP
(3800W)
|
7.5HP
(5600W)
|
10HP
(7500W)
|
|
Noise Level
(idling)
|
68~72dB
|
68~72dB
|
70~75dB
|
70~75dB
|
70~78dB
|
|
Abrasive Wheel
(Diameter & Arbor)
|
Ø305 × Ø31.75(Ø32)mm
|
Ø406 × Ø32mm
|
|
Flange Diameter
|
Ø85
|
Ø85 & Ø100
|
|
Feed Rate
|
Standard: 10~150 mm/min
Option:10~75 mm/min
|
Standard:10~75 mm/min
(Special feed rate can be customized)
|
|
Feed Method
|
Automatic
|
Home point return after cutting
|
|
Manual
|
Hand wheel and button control
|
|
Rotational Speed
|
2500RPM(60Hz) / 2100RPM(50Hz)
|
|
Vise
|
Dual quick push clamp vise
|
|
Vise Dimension
(WxH)
|
100mm x 60mm
|
150mm x 60(85)mm
|
200mm x 60(85)mm
|
|
Movement in
X-axis
|
45mm
|
|
Pump Motor Power
|
1/4HP (190W) Thee phases
|
|
Recirculation Cooling System
|
100L
|
120L
|
|
Machine Dimension
(WxDxH)
|
105 x 110 x 155cm
|
105 x 125 x 162cm
|
105 x 145 x 162cm
|
|
Machine Weight
|
358Kg
|
365Kg
|
454Kg
|
476Kg
|
503Kg
|
|
Voltage
|
AC 220V/380V /415V/440V Three phases
(Special voltage can be customized)
|
|
Standard Accessories
|
Wrench x 2pcs, cut off blade x 2pcs
|
|
Coolant 5L
|
Coolant 6L
|
