| Measuring range |
600.00 to 1100.00hPa |
| Resolution |
0.01hPa |
Accuracy
(at 10 to 40C) |
±0.50hpa (700.00 to 1100.00hPa)
±1.00hpa (other than above) |
| Sampling time |
approx. 1 sec. |
| Sensing element |
Piezoresistance pressure sensor |
| Display |
7 segment red LED (6 digits) Status indication: red LED |
| Operation ambient |
-10°C to 50°C, less than 85 %rh (no condensing) |
| Power requirement |
9VDC (exclusive AC adapter in 100 to 240VAC use) 660mA 50/60Hz |
| Materials |
Main Body: SPCC
Display: acryl resin
Pressure port: SUS304 |
| Dimensions |
(W)200×(H)90×(D)280 mm |
| Weight |
appricx. 3.0 kg |
| Accessories |
Instruction manual, exclusive AC adapter x 1
RS-232C cable x 1
USB serial cable (with CD-ROM for USB driver) x 1 |
