| Measuring range: |
0.75mm~300.0mm(0.03inch~11.8inch) |
| Units: |
Metric/Imperial unit seletable |
| Sound Velocity Range: |
1000m/s~9999m/s(0.039~0.394in/μs
|
| Display resolution: |
0.01mm or 0.1mm(lower than 100.0mm)
0.1mm(more than 99.99mm) |
| Accuracy: |
±(0.5%Thickness+0.04)mm,depends on Materials and conditions |
| Data Memory: |
5 files(up to 100 values for each file)of stored values
5 Sound Velocity of stored values |
| Power Source: |
2pcs 1.5V AA size,batteries.100 hours typical operating time(LED backlight off) |
| Outline Dimensions: |
150mm*74mm*32mm |
| Workpiece surface temperature: |
- 10 ~ 60 ºC |
| The minimum thickness value capture capacity |
With a minimum thickness value capture capacity |
| Standard configuration |
NDT310 host, 5MHz probe, English instruction manual, coupling agent(Empty bottle) |
| Measurement cycle: |
4 times/SEC, scanning of single point measurement model 20 times per second. |
| Weight: |
238 g |
| Power source: |
Type AA alkaline battery 1.5 V (2) |
