| Type |
TI-45NA |
TI-45BA |
TI-45CA |
| Measuring range |
1.00 to 199.99mm |
0.40 to 15.00mm |
0.50 to 19.00mm |
| Pipe |
Diameter (mm) |
ø27.2 or more |
ø10.50 or more |
ø10.50 or more |
| Thickness (mm) |
1.50 or more |
1.50 or more |
0.80 or more |
| Tolerance resolution |
± 0.05mm or ± 0.2% rdg |
± 0.03mm |
± 0.03mm |
| Display |
4 1/2-Digit LCD display, with push button backlighting |
| Display resolution |
0.01 mm |
| Velocity range |
1000 to 12000m/s |
| Cable |
1m long cable with locking, quick removable connections |
| Battery |
One AA Battery |
| Calibration Plate |
5.00mm steel plate integrated into front of housing |
| Size |
W69mm x H144mm x D29.5mm |
| Weight |
Gauge: 150 ± 10g,
Probe type 5Z10NDT-M: 50 ± 10g,
Probe type 10Z10NDT-B: 50 ± 10g,
Probe type 10Z6NDT-A: 35 ± 10g |
| Temperature |
-5 to 50°C(Ambient・Materials) |
| Warranty |
Gauge: 1year , Probe: 6months |
