| Power supply |
Rechargeable lithium-ion battery pack 9.6V, backup charger. |
| Battery indicator |
Battery symbol shows dump energy. When the voltage is too low, automatic shutdown after the 1 minute. |
| Power consumption |
Current consumption of normal test 490 mA, continuous working for 8 hours. |
| Display mode |
LCD color screen, 640dots×480dots, 5.6 inches, display domain: 116mm×88mm. |
| Size of clamp |
008B small sharp current clamp: 7.5mm×13mm; |
| Instrument dimensions |
L×W×H: 240mm×170mm×68 mm. |
| Number of channels |
4U/4I. |
| Phase-to phase voltage |
1.0V~2000V. |
| Phase-to-neutral voltage |
1.0V~1000V. |
| Current |
008B current clamp: 10mA~10.0A; |
| Frequency |
40Hz~70Hz. |
| Parameters of electricity |
W, VA, Var, PF, DPF, cosφ, tanφ. |
| Energy parameters |
Wh, Varh, Vah. |
| Harmonic |
Order 0~50. |
| Total harmonic distortion |
Order 0~50, each phase. |
| Expert mode |
Yes. |
| Number of Transient records |
150 sets. |
| Voltage flicker |
Yes. |
| Starting current mode |
Yes, 100 seconds. |
| 3 phases unbalance |
Yes. |
| Record |
300 days(simultaneous recording 20 parameters, record one point every 5 seconds). |
| Min/Max recorded value |
Measurement of maximum and minimum values over a period of time. |
| Alarm |
40 different types of parameter selections, 12,800 sets alarm logs. |
| Peak |
Yes. |
| Phasor diagram display |
Automatically. |
| Capacity of snapshots |
60. |
| Menu language |
English |
| Communication |
USB. |
| Automatic switching off |
When an alarm campaign is initiated or a search for transients, an inrush current capture, or a trend recording is pending or in progress, the device is not automatic switching off. |
| In other test mode, 15 minutes without keystrokes, automatic shutdown after prompt 1 minute. |
| Backlight function |
Yes, suitable for use at night and dark place. |
| Weight |
Host: 1.6kg (with battery). |
| 008B small sharp current clamp: 170g×4; |
| Length of voltage test wire |
3m. |
| Length of current sensor wire |
2m. |
| Working temperature and humidity |
-10°C~40°C; below 80%Rh. |
| Storage temperature and humidity |
-10°C~60°C; below 70%Rh. |
| Input impedance |
Input impedance of test voltage: 1MΩ. |
| Withstand voltage |
Withstand 3700V/50Hz sinusoidal AC voltage for 1 minute between instrument wiring and shell. |
| Insulation |
Between instrument wiring and shell ≥10MΩ. |
| Structure |
Double insulation, with insulation vibration-proof sheath. |
| Safely rules |
IEC 61010 1000V Cat III / 600V CAT IV, IEC61010-031, IEC61326, Pollution degree: 2. |
