Range
10³-10¹²+ Ohms per Square.
Resolution
One order of magnitude.
Changeover Point
½ decade on logarithmic scale (3.15 x 10 n).
Accuracy of Changeover Point
+/- ½ decade.
Accuracy
+/- 10%. Repeatability: +/- 5%.
Test Operation
Test battery - press button when holding in free air - the red insulative LED should illuminate.
Battery
9 V PP3 alkaline.
Dimensions
70 x 130 x 35 mm ( W x H x D).
Weight
103 g.
Equipment
Meters are supplied with carrying case, battery and earth lead for resistance to ground measurement.
