| Parameters |
Leakage current |
| Accuracy |
2% |
| Output Voltage |
No internal voltage source |
| Measurement Range |
Current: 10nA~20mA |
| Max Reading |
8 channel in parallel/9999 |
| Range |
Manual |
| Charging Current |
\ |
| Speed |
20t/s |
| Result Display |
Direct reading |
|
\ |
| Charging Timer |
\ |
| Comparator |
10 level comparator independently output |
| Beep |
OK,NG,Switch off setting and voice volume setting |
| Interface |
RS-232 interface, Handler interface |
| Power Supply |
Voltage: 198VAC～240VAC Frequency: 50Hz |
| Dimension & Weight |
Outer size(mm): 264(W)X107(H)X350(D) Inner size: 216(W)X88(H)X323(D) 5kg |
