Test voltages
1 kV - 2 kV - 5 kV - 10 kV.
Maximum resistance reading
200 GΩ @ 1 kV.
400 GΩ @ 2 kV.
1 TΩ @ 5 kV.
2 TΩ @ 10 kV.
Short circuit current
1 mA.
Test voltage accuracy
± 2% of nominal test voltages on R ≥ 10 GΩ.
Internal current limiting resistance
1 MΩ @ 1 kV.
2 MΩ @ 2 kV.
5 MΩ @ 5 kV.
10 MΩ @ 10 kV.
Insulation tester Accuracy
Class 2 (±2 % of full scale deflection).
Analogue indicator
Up to 98 mm scale length, taut band, with mirror.
Environmental protection
IP54 with closed lid.
Safety class
In accordance with 61010-1.
E.M.C.
In accordance with 61326-1.
Electro magnetic irradiation immunity
In accordance with IEC 61000-4-3.
Electrostratic immunity
In accordance with IEC 61000-4-2.
Power supply
Internal rechargeable 12 V - 7 Ah sealed lead acid battery.
Battery charger
For 110-127 or 220 V.a.c. mains supply.
Operating temperature range
-5 °C to +50 °C.
Storage temperature range
-25 °C to +70 °C.
Humdity
95 % UR (non condensing).
Weight
Approx. 9.5 kg.
Dimension
378 x 308 x 175 mm.
