DC Winding resistance
|
Current step
|
Measurement range
|
|
1mA
|
500Ω~50kΩ
|
|
10mA
|
50Ω~2kΩ
|
|
100mA
|
10Ω~200Ω
|
|
1A
|
100mΩ~20Ω
|
|
5A
|
10mΩ~1Ω
|
|
10A
|
500uΩ~200mΩ
|
● Accuracy: ±(reading*0.2%+2 digits)
● Min. resolution: 0.1uΩ
● Weight: 1.6kg (without test lines)
● Size: 246*156*62mm
Use conditions
● Power supply: 100~240VAC, 50/60Hz
● Lithium battery
● Charging voltage: 16.8V
