| Working power |
DC: built-in 12.6V/7.5Ah Lithium battery(with power adapter) |
| Test current |
50A,100A |
| Measurement range |
50A: 0~20mΩ
100A: 0~10mΩ |
| Accuracy |
± (0.5%+1uΩ) |
| Resolution |
0.1uΩ |
| Display |
Large-screen color LCD display, can be clearly displayed in the sun. |
| Test power supply |
Constant current and voltage limiting, about 2V |
| Input voltage |
Max. 5V |
| Test time |
Quickly, 10s, 20s, 30s, 60s optional |
| Battery capacity |
Built-in 12.6V/7.5AH lithium battery |
| Measurement time |
More than 600 times (rechargeable, fast measurement mode) |
| Test wire |
Resistance less than 10mΩ |
| Temperature |
Working: -10~40℃
Storage: -20~50℃ |
| Humidity |
≤80%RH, no condensation |
| Dimension |
280*160*60mm |
| Host weight |
1.8kg (with battery, without test cables) |
