Test current
From 5 A up to 200 A (True DC).
The test current can be adjusted in steps of 0.2 A from 5 A to 20 A and steps of 1 A from 20 A to 200 A.
Resistance ranges
0.1 µΩ to 2 mΩ, with 0.1 µΩ resolution.
2 mΩ to 200 mΩ, with 10 µΩ resolution.
200 mΩ to 1 Ω, with 1 mΩ resolution.
Measurement principle
Four-terminal, Kelvin-type.
Test with programmable time
Allows programming the test period of 5 seconds to 120 seconds.
Basic accuracy
± 1% of measured value.
Advanced features
Digital direct reading of very low resistances in the alphanumerical display, with up to 4½ digits. Very fast and accurate measurements.
Interface
USB.
Software MegaLogg2
Friendly, easy to use software. With automatic report generator, including the operator's commentaries.
Environmental protection
IP54 with closed lid.
Safety class
Meets the requirements of IEC 61010-1.
Power supply
Mains supply: 100-240 V~.
Operating temperature range
-5 °C to +50 °C.
Storage temperature range
-10 °C to 70 °C.
Humidity range
95% UR (non condensing).
Equipment weight
Approx. 11 kg.
Dimensions
502 x 394 x 190 mm.
