| Spectrometer: |
|
Carl Zeiss MMS-1 Spectrometer |
| Range: |
|
310-1100 nm |
| Spectral Sample Size: |
|
3 nm |
| Spectral Resolution: |
|
8-13 nm |
| Light Source: |
|
Xenon Tungsten Lamp |
| Lens: |
|
Fused silica, coated to enhance NIR |
| Shutter: |
|
White painted reference standard |
| Display: |
|
Sunlight visible transflective LCD screen |
| PC Interface: |
|
Connectivity: USB & WiFi |
| Data Recorded with Each: |
|
Raw data, reflectance, absorbance, first derivative |
| Operating Conditions |
|
0-50ºC, 0-90% non-condensing humidity |
