Instrument Specifications
|
|
Display Type
|
1.77 inch OLED with resolution 160x128 pixels
|
|
Hardness Scale
|
HL, HB, HRB, HRC, HV, HS. σb.
|
|
Measuring Range
|
HLD (200-960) HRC(19.8-68.5) HB(30-651) HV(80-976) HS(26.4-99.5) HRB(13.5-100).σb.(375-2639)
|
|
Impact Device
|
D type impact device (Standard); DL type impact device
|
|
Accuracy
|
±6HLD (HLD=800), Repeatability < 6HLD (HLD=800)
|
|
Measuring direction
|
360 degree by manual setting
|
|
Material
|
Steel & Cast Steel, Stainless Steel, GC IRON, NC IRON, Cast Aluminum alloy, Macht metal,
Copper-tin alloy, Brass, Forged Steel
|
|
Resolution
|
1HL, 1HV, 1HB, 0.1HRB, 0.1HRC, 0.1HS
|
|
Calibration
|
Automatic
|
