| Accelerometer |
Piezo-electric (10pc/g) |
| Acceleration Range |
0.1 to 1000 ms-2 (0.01 to 100 g) |
| Velocity Range |
0.1 to 1000 mms-1 |
| Displacement |
1 to 1000μm (Above in RMS or Peak and in 2 ranges) |
| Mechanical Filter Frequency |
10Hz - 1KHz |
| Linear Filter Frequency |
10Hz - 10KHz |
| Memory |
non-volatile E2PROM memory which holds calibration data plus storage of 9 spot results. |
| Keypad |
9 Key Tactile Keypad |
| Standards |
BS6842 Compliance with EMC CE marking |
| Display |
8 Character LCD Display |
| Parameters |
Acceleration, Velocity, Displacement |
| Filters |
Mechanical & Linear |
| Detectors |
RMS and Peak |
| Displays |
rms, Lmax, Lpeak |
| Overload Indication(flashing display) |
Battery condition indication, Low Battery (Flashing alternate display), Hi/Lo range |
| Calibration |
Simple calibration offset accessed from the keypad and stored in the non-volatile memory |
| Weight |
250g with batteries |
| Size |
135 x 62 x 30mm |
| Batteries |
1 x IEC No 6LR61 (Upto 40 hrs life with Duracel MN1604) |
