| Instrument Standards |
ISO 8041 : 2005 Human Response to Vibration
For compliance with:
ISO 5349 : 2001 Measurement and evaluation of human exposure to hand-transmitted vibration |
| Range (Integration = Acceleration) |
Low: 0.05 - 200.0m/s-2 / 0.005 - 20.4g
High: 0.50 - 2000.0m/s-2 / 0.05 - 204.0g |
| Measurement Channels |
One |
| Parameters |
Acceleration: Arms, Aeq, Amax, Peak, Vector Sum, HSE Exposure Points, EAV and ELV |
| Linear Operating Range |
72dB |
| Frequency Weighting |
WH - Hand Arm Filter |
| Memory |
Flash memory storing up to 992 recordings |
| Transducer |
Castle KD1010, 10mV/g |
| Noise Floor |
<0.002 m/s-2 - Low Range
<0.020 m/s-2 - High Range |
| Display |
Full Colour Graphic OLED Display (160 x 128) |
| Batteries |
NiMH re-chargeable cell pack
Typically 10 hours continuous use |
| Connections |
Input: 3.5mm Stereo Jack Socket
AC Output: 4 Pole 3.5mm Jack Socket
Download: USB Micro B (Cable Supplied)
Recharge: DC Socket (Charger & Cable Supplied) |
| Languages |
English UK, English US, Chinese, French, German, Italian, Portuguese Brazilian, Russian, Spanish |
| Temperature Operating Range |
-10 to + 50ºC |
| Humidity |
Up to 90% RH Non Condensing |
| Electromagnetic Compatibility |
Designed in accordance with the following Electromagnetic Compatibility Directives:
SI 2005/281
2004/108/EC |
| Case |
High Impact ABS plastic with tactile membrane keypad |
