isplay
52 mm x 38 mm, LCD Display.
16 mm (0.63”) Digit size.
With bargraph indicator.
Measurement
Velocity, Acceleration, Displacement.
Function
Main: RMS, Peak, Max. hold.
Others: Data hold, Max. & Min. value, Data logger.
Frequency range
10 Hz to 1 kHz.
Sampling time
Approx. 1 second.
Sampling time
0, 1, 2, 10, 30, 60, 600, 1,800, 3,600 seconds.
* 0 second: Manual data logger.
* Other sampling time beyond 0 second: Auto data logger.
Data logger#
500 max.
Data output
RS232 serial output, isolate.
Operating humidity
Less than 80% RH.
Operating temperature
0 ºC to 50 ºC.
Power supply
Alkaline or heavy-duty type, DC 9V battery, 006P, MN1604 (PP3) or equivalent.
Power consuption
Approx. DC 13 mA.
Weight
253 g.
Dimension
200 x 68 x 30 mm.
Acceleration
Unit = m/s².
Range = 0.5 to 199.9m/s².
Resolution = 0.1m/s².
Accuracy = ± (5% + 2d) reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50m/s² (160Hz).
Unit = G (1G = 9.8m/s²).
Range = 0.05 to 20.39G.
Resolution = 0.01G.
Accuracy = ± (5% + 2d) reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50 m/s² (160 Hz).
Unit = ft/s².
Range = 2 a 656 ft/s².
Resolution = 1 ft/s².
Accurace = ± (5% + 2d) reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50 m/s² (160 Hz).
Velocity
Unit = mm/s.
Range = 0.5 to 199.9 mm/s.
Resolution = 0.1 mm/s.
Accuracy = ± (5% + 2d) Reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50 mm/s (160 Hz)
Unit = cm/s.
Range = 0.05 to 19.99 cm/s.
Resolution = 0.01 cm/s.
Accuracy = ± (5% + 2d) Reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50 mm/s (160 Hz).
Unit = in/s.
Range = 0.02 to 7.87 in/s.
Resolution = 0.01 in/s.
Accuracy = ± (5% + 2d) Reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 50 mm/s (160 Hz).
Desplacement (peak to peak).
Unit = mm.
Range = 1.999 mm.
Resolution = 0.001 mm.
Accuracy = ± (5% + 2d) reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 0.141 mm (160 Hz).
Unit = inch.
Range = 0.078 in.
Resolution = 0.001 in.
Accuracy = ± (5% + 2d) reading @ 160Hz, 80Hz, 23 ± 5 ºC.
Calibration point = 0.141 mm .(160 Hz)
