| General Specifications |
| Amplitude Ranges |
Acceleration: 0.01 to 19.99g (RMS)
Velocity: 0.01 to 19.99 in/sec (RMS)
0.1 to 199.9 mm/sec (RMS)
Envelope: 0.01 to 19.99 ge (PEAK) |
| Frequency Ranges |
Overall: 10 Hz to 10 kHz |
| Envelope |
0.5 kHz to 10 kHz |
| Display Indications |
LCD 3.5 digit with Measurement,Hold and Low Battery |
| Vibration Sensor |
Piezoelectric Accelerometer100 mV/g |
| Output |
Audio: (3.5 mm) mini plug |
| Sensor Power |
12 Vdc |
| Power |
(2) “AA” cell batteries |
| Operating Time |
20 hours continuous without phones |
| Environmental |
-14 to 122°F (-10 to 50°C) |
| Dimensions |
6.3 x 3.3 x 1.25” (1.52 x 83 x 32 mm) |
| Weight |
2.85 lbs. (1.30 kg) |
