| Working condition |
-15℃~40℃ |
RH<80% |
| Anti-interference principle |
Frequency conversion |
| Power supply |
AC 220V±10% |
Generator can be used. |
| High voltage output |
0.5KV~10KV |
Every 0.1kV |
| Accuracy |
2% |
| Max. current |
200mA |
| Capacity |
2000VA |
| Self-excitation power |
AC 0V~50V/15A |
45HZ/55HZ 47.5HZ/52.5HZ
55HZ/65HZ 57.5HZ/62.5HZ
Automatic dual frequency |
| Resolution |
tgδ: 0.001% |
Cx: 0.001pF |
| Accuracy |
∆tgδ: ±(reading*1.0%+0.040%) |
| ∆C x: ±(reading*1.0%+1.00PF) |
| Measurement range |
tgδ |
Without limit |
| C x |
15pF < Cx < 300nF |
| 10KV |
Cx < 60 nF |
| 5KV |
Cx < 150 nF |
| 1KV |
Cx < 300 nF |
| CVT test |
Cx < 300 nF |
| LCR measurement range |
L>20H(2kV) |
R>10KΩ(2kV) |
| LCR measurement accuracy |
0.1% |
Angle resolution |
0.01 |
| CVT ratio range |
10~10000 |
| CVT ratio accuracy |
0.1% |
| CVT ratio resolution |
0.01 |
| Dimension |
Main unit: 470(L)×370(W)×380(H) |
| Accessory box: 430(L)×350(W)×130(H) |
| Memory capacity |
200 groups, USB flash disk storage is supported. |
| Weight |
Main unit: 22.75Kg |
| Accessory box: 5.25Kg |
