| Test Functions |
L,C.R,Z,D,Q |
| Accuracy |
0.1% |
| Measurement Frequency |
100Hz, 120Hz, 1kHz, 10kHz |
| Measurement Range |
AUTO/HOLD, 6 Ranges |
| Measurement Speed |
15 times/s, 5 times/s, 3 times/s |
| Display Range |
L: 0.01μH-9999H
C: 0.01pF – 9999μF
R,X,Z: 0.0001Ω - 99.99MΩ
D, 0.0001 – 9.9999
Q: 0.0001 – 9999.9 |
| Source Resistance |
30Ω/100Ω |
| Monitor Parameter |
Z, D, Q, θ, ΔABS, Δ% |
| Display Reader |
5 digits: 99999 |
| Equivalent Circuit |
Serial and Parallel |
| Signal Level |
10.00mV~2.00V AC
100.0μA~20.00mA AC |
| Trigger Mode |
INT/HOLD/MAN/BUS |
| Comparator |
P1/P2/P3/AUX/NG |
| Comparator Mode |
SEQ/ABS/PER |
| Adjustment |
OPEN/SHORT Zeroing |
| Beep Feature |
OFF/P1/P2/P3/AUX/OUT |
| Interface |
RS232/Handler |
| Protocol |
SCPI |
| Power Supply |
AC 198V-240V, 50Hz-60Hz
15W MAX |
| Dimension & Weight |
264(W)x107(H)x350(L)
4kg, net |
