| Model |
TS7030 |
| Optical Geometry |
D/8(diffused illumination, 8-degree viewing angle) |
| SCI/SCE Mode |
| Comply to CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 |
| Characteristic |
single apertures, more adaptability; Used for accurate color measurement and quality control in plastic electronics, paint and ink, textile and garment printing and dyeing, printing, ceramics and other industries |
| Integrating Sphere Size |
Φ40mm |
| Light Source |
Combined full spectrum LED light source, UV light source |
| Spectrophotometric Mode |
Flat Grating |
| Senso |
Silicon photodiode array (double row 32 groups) |
| Wavelength Range |
400～700nm |
| Wavelength Interval |
10nm |
| Semiband Width |
10nm |
| Measured Reflectance Range |
L:0~120; reflectivity:0~200% |
| Measuring Aperture |
Single Apertures：Φ8mm/Φ10mm |
| Specular Component |
SCI/SCE |
| Color Space |
CIE LAB,XYZ,Yxy,LCh,s-RGB,βxy,Munsell(C/2) |
| Color Difference Formula |
ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99 |
| Other Colorimetric Index |
WI(ASTM E313,CIE/ISO,AATCC,Hunter)， |
| YI(ASTM D1925,ASTM 313), |
| Metamerism Index MI, |
| Staining Fastness, Color Fastness, Color Strength, Opacity,Color Card Search |
| Observer Angle |
2°/10° |
| Illuminant |
D65,A,C,D50,F2(CWF),F7(DLF),F10(TPL5),F11(TL84),F12(TL83/U30) |
| Displayed Data |
Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset |
| Displayed Accuracy |
0.01 |
| Measuring Time |
About 1.5s (Measure SCI & SCE about 3.2s) |
| Repeatability |
Chromaticity value: MAV/SCI, within ΔE*ab 0.06 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) |
| Inter-instrument Error |
MAV/SCI, Within ΔE*ab 0.3
(Average for 12 BCRA Series II color tiles) |
| Measurement Mode |
Single Measurement, Average Measurement(2-99times) |
| Locating Method |
Camera Locating,stabilizer cross position |
| Dimension |
L*W*H=81X71X214mm |
| Weight |
About 460g |
| Battery |
Li-ion battery, 6000 measurements within 8 hours |
| Illuminant Life Span |
5 years, more than 3 million times measurements |
| Display |
3.5-inch TFT color LCD, Capacitive Touch Screen |
| Data Port |
USB |
| Data Storage |
Standard 1000 Pcs, Sample 20000 Pcs(One data is able to include SCI/SCE) |
| Language |
Simplified Chinese, English, Traditional Chinese |
| Operating Environment |
0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment |
-20~50℃, 0~85%RH (no condensing) |
| Standard Accessory |
Power Adapter, USB Cable, User Guide, SQCX Software(Download from office website), White and Black Calibration Cavity, Protective Cover, Wrist strap, 8mm flat aperture, 8mm tip aperture |
| Optional Accessory |
USB Micro Printer, Powder Test Box, |
| Notes |
Technical parameters are only for reference, subject to the actual sale of the product |
