| OVERVIEW |
| Internal Memory |
8 GB |
| Laser Orientation |
Single laser pointer to center of thermal image |
| Packaging Size |
55 × 31 × 32 (21.6 × 12.3 × 12.4 in) |
| Sensitivity |
<70 mK |
| Typical Usage |
4 work weeks |
| Warranty |
10 year |
| COMPLIANCE & CERTIFICATIONS |
| Agency Approvals |
CE, FCC Class B, RCM |
| ENVIRONMENTAL |
| Drop test |
3 m (9.8 ft) |
| Mixing Ratio |
Range 0 to 560 GPP (0.0 to 80.0 g/kg) / Basic Accuracy ±2 GPP (0.25 g/kg) |
| Relative Humidity |
Range 0 to 100% / Basic Accuracy 2.5% RH |
| Vapor Pressure |
Range 0.0 to 12.0 kPa / Basic Accuracy ±0.05 kPa |
| IMAGING & OPTICAL |
| Continuous Run Time |
16 hours max |
| Digital Camera |
2 MP, 70.5° × 56° FOV |
| Display Type |
QVGA (320 × 240 pixels) 2.8 in. color TFT graphical display |
| Image Modes |
Thermal, Visual, MSX® |
| Image Update Speed Frequency |
9 Hz |
| Imaging Detector |
FLIR Lepton microbolometer |
