| Sampling Method & Range |
Diffusion 0-50,000ppm |
| Accuracy |
±300 ppm, ± 3% of measured value |
| Operating Temperature |
-0 to + 50° C |
| Display |
¾” backlit LCD digital display |
| Sensor Type |
Non-dispersive infrared (NDIR) |
| Alarm indicators |
Built-in Audible 90dB horn, LED alarm |
| Signal Outputs |
Two user-adjustable Alarm relays. Relays are rated 2 amp 24VDC / 24VAC |
| Analog Output |
Analog 4-20mA output (Active) |
| Power Requirements |
24VDC 350mA |
| Dimensions |
6.5 (W) x 4.5 (H) x 3.25 (D) inches; (165.1 mm x 114.3 mm x 82.5 mm) |
| Weight |
1.6 lbs. (.8 kg) |
| Enclosure |
Polycarbonate |
| Required calibration |
None when Auto Calibration function is activated |
| Country of Origin |
USA |
| Harmonized Tariff Code |
8531.10.0045 |
