| Sampling Method |
Extractive Sample Draw |
| Gases Detected |
Carbonyl Sulfide (COS) |
| Range1 |
0 – 50ppm |
| Accuracy |
0.5 ppm |
| Operating Temperature |
-0° to 50°C (0° to +30°C) |
| Sensor Type |
Disposable electrochemical cell |
| Sensor Life |
2-3 years under normal conditions |
| Gas Concentration Indicator |
Built-in LCD Back-Lit Digital Display – Displays, Gas Name, ppm Concentration, AL1, AL2, System Fault Messages |
| Signal Outputs |
4-20 mA Analog Output (Active) |
| Alarm Level 1 |
Yes |
| Alarm Level 2 |
Yes |
| Fault |
Yes |
| Sampling Distance2 |
100 ft |
| Sample Pump |
Electromagnetic DC Diaphragm Pump |
| Power Requirements |
2.0 A 24 VDC |
| Width |
10.0 in 254 mm |
| Height |
6.5 in 165.1 mm |
| Depth |
8.05 in 204.5 mm |
| Weight |
10 lb (4.5 kg) |
| Enclosure |
Polycarbonate |
