| O2 RANGE |
0.1 to 25%
|
| SENSOR ACCURACY |
Better than ± 0.75% O2 over 5.0 to 25.0% O2
|
| RESPONSE TIME (T90) |
<60 seconds
|
| OPERATING TEMPERATURE |
0 to +40 °C (+32 to +104 °F)
|
| TEMPERATURE EFFECT |
0.2% of reading/°C or 0.1115% of reading/ °F
|
| ATMOSPHERIC PRESSURE RANGE |
811 to 1050 mbar absolute
|
| WARM UP TIME |
10 seconds to normal operation, prior to calibration allow 2 hours to achieve full accuracy
|
| DIMENSIONS |
Central unit = 175 x 105 x 75 mm, alarm repeater = 155 x 72 x 45 mm
|
| WEIGHT |
Central unit = 600g, Alarm repeater = 150g
|
| IP RATING |
IP65 for central unit and alarm repeater, unless the alarm repeater is quick connect then it is IP43
|
| SENSOR TYPE |
Electrochemical cell
|
