Measurement method
|
Electrochemical measuring principle (with sensor from Membrapor)
|
|
Ambient temperature
|
-20℃ ~ +60℃
|
|
Measurement range
|
SO2: 0~200PPmv, H2S: 0~200PPmv
CO: 0~500PPmv, HF: 0~50PPmv
|
|
Error
|
SO2: <10PPmv, ±0.3PPmv; >10PPmv, ±3%
H2S: <10PPmv, ±0.3PPmv; >10PPmv, ±3%
CO: <50PPmv, ±2PPmv; >50PPmv, ±4%
HF: <10PPmv, ±0.3PPmv; >10PPmv, ±3%
|
|
Repeat-ability
|
SO2: <10PPmv, ±0.2PPmv; >10PPmv, ±2%
H2S: <10PPmv, ±0.2PPmv; >10PPmv, ±2%
CO: <50PPmv, ±2PPmv; >50PPmv, ±2%
HF: <10PPmv, ±0.2PPmv; >10PPmv, ±2%
|
|
Resolution
|
0.1PPmv
|
|
Display unit
|
PPmv
|
|
Gas flow
|
200 ~ 300ml/min
|
|
Gas flow display
|
0~1000mL imported digital gas flow meter
|
|
Gas pressure
|
≤1MPa
|
|
Humidity
|
90%RH
|
|
Measurement value influence
|
No effect of pressure and flow
|
|
Power supply
|
220VAC±10%, 50Hz, AC/DC use, continuous working is more than 8 hours.
|
|
Size
|
395*295*155mm
|
|
Weight
|
2kg
|
