Display:
|
LCD display with 6 numeric 0.506 inch (12.85mm) high digits and 5 alphanumeric 0.282inch (7.11mm) high digits
|
|
Indicators:
|
Battery level, On Target, Select, TACH, and EXT icons
|
|
Memory:
|
Last setting before power down is remembered and restored on next power up. 5 user settable memory locations
|
|
Flash Duration:
|
Adjustable 0.5 to 2500 microseconds or .1 to 18 degrees of rotation (auto adjusts with flash rate)
|
|
Safety:
|
This product is designed to be safe for indoor use under the following conditions (per IEC61010-1)
|
|
Compliance:
|
CE EN61326-1:2006 EMC 2004/108/EC
|
|
Operating Temp:
|
32-104°F (0-40°C)
|
|
Humidity:
|
Maximum relative humidity 80% for temperature up to 88°F (31°C) decreasing linearly to 50% RH at 104°F (40°C)
|
|
Input Power:
|
Battery powered: Internal Li-Ion rechargeable batteries 3.6Vdc
|
|
Light Source:
|
7 LED Array
|
|
Light Output:
|
Average: 1800 Lumens at 6000 FPM 8” from lens
|
|
Color Temp:
|
5600°K
|
|
Run Time:
|
5 hours typical at 6000 FPM, and 2.8° pulse width with fully charged batteries
|
|
Charge Time:
|
4-5 hours typical with supplied charger
|
|
Weight:
|
0.6 lbs (0.27kg) including batteries
|
|
Dimensions:
|
7.75" x 2.75" x 2.3" (197 x 70 x 58 mm)
|
