| Range |
Resolution |
| Measuring Range |
0.40 - 25000 RPM (floating decimal point) 0.40 - 2000.0 ft/min (w/12" wheel) |
| Accuracy |
0.01% of reading ± 1 digit |
| Display |
5 digit LCD 12mm Character Height |
| Measuring Unit* |
Speed Mode: RPM, rev/sec, FPM, in/min, yd/min, in/sec, m/min, cm/min, cm/sec Counter Mode: revolutions, ft, in, yd, m, cm |
| Measuring Mode |
MEAN, MAX, MIN (speed measure mode) |
| Memory |
Short Term Auto Memory: MAX, MIN, MEAN and last 9 data Long Term On-Demand memory: 99 data |
| Display Update |
0.5 sec or 1.0 sec selectable |
| Power |
2 - AA Battery, Approx. 80 hrs continuous operation |
| Indicators |
LOW BATT, Units, MAX, MIN, MEAN and memory location |
| Operating Temp. |
0 - 45°C (32 - 113°F) |
| Construction |
Die-cast aluminum housing |
| Standard Accessories |
Cone adapter, funnel adapter, 2-AA Batteries, NIST traceable Certificate |
| Optional Accessories |
12" wheel (surface speed measuring wheel is necessary to measure linear speed), 3-1/2" Extension Shaft. |
