Measuring range:
(floating decimal point) |
Revolution: 0.1 – 25000 rpm; 6 – 9999.9 rph
Speed: z. B. 0.02 – 3810 m/min; 0.9 – 99999 m/h; 0.6 – 99999 in/min;
0.05 – 12500 ft/min; 3 – 99999 ft/h; 0.02 – 4167 yd/min; 1.0 – 9999 yd/h; 0.0006 – 142.5 mil/h
Length: 0.5 – 99999 cm; 0.005 – 99999 m; 0.1 – 9999.9 in; 0.01 – 99999 ft; 0.005 – 9999.9 yd |
| Accuracy: |
Revolution: 0 – 999.9 rpm (±0.1 rpm) ±1 digit
1000 – 9999.9 rpm (±1 rpm) ±1 digit
10000 – 25000 rpm (±0.01% of reading) ±1 digit
Speed and length: ±0.4 % of reading, ±1 digit |
| Measuring units: |
Revolution: rpm, rph;
Total revolutions (counter): rev
Speed: m/min; m/h; ft/min; ft/h; yd/min;yd/h; in/min; in/h; mil/h
Length: cm; m; in; ft; yd |
| Memory: |
MIN + MAX + last 4 values |
| Resolution: |
Length: 0.00254 m/impulse (with 6 inch measuring wheel)
Revolution: 60 impulse/revolution |
| Display: |
5 digit, LCD 12 mm |
| Display update: |
1 sec |
| Over range indicator: |
Display is flashing |
| Auto power off: |
After 5 min of non-use |
| Power supply: |
2 x 1.5 V Type AA; approx. 65 h continuous use |
| Low battery indicator: |
“LO BAT” flashes at the display |
