Input
4 voltage / 4 current
Voltage measurement
50 - 500 Vac
Resolution
0.1 V
Accuracy in voltage measurement
0.5% ± 2 digits
Current measurement
Up to 5 A (optional clamp)
Up to 600 A (optional Rogowsky coils)
Up to 3000 A (optional Rogowsky coils)
Resolution
0.01 A (with sensor up to 5 A)
0.1 A (with sensor up to 600 A)
1 A (with sensor up to 3000 A)
Current measurement accuracy
0.5% ± 2 digits
Frequency measurement
45 - 65 Hz
Active power measurement
Up to 1.5 MW per phase (current sensor dependant)
Resolution
1 W (with sensor up to 5 A)
Reactive power measurement
Up to 1.5 MVAR per phase (current sensor dependant)
Resolution
1 VAR (with sensor up to 5 A)
Accuracy in power measurement
1% ± 2 digits
Power factor measurement
-1.00 to 1.00
Resolution
0.01
Phase sequence
Direct or inverse sequence indication
Environmental protection index
IP54 (with closed lid)
Safety
Meets the requirements of IEC 61010-1
Operating temperature range
-10 °C to 50 °C
Storage temperature range
-25 °C a 65 °C
Humidity range
95 % RH (non condensing)
Power supply
Internal NiMH rechargeable battery, 6 x HR6 (AA)
Built-in battery charger
AC adapter 12 V - 1 A or 5 V - 2 A
Display
Graphic LCD of 128 x 64 px
Equipment weight
Approx. 1.7 kg
Dimensions
221 x 189 x 99 mm
