Model
|
ML25C
|
ML25.4C
|
ML30C
|
ML38.1C
|
ML40C
|
|
ML31.75C
|
ML32C
|
|
ML50C
|
|
|
Sample Quantity
|
1~2 pcs/per time (optional spacer for 2pcs)
|
|
Spacer (Optional)
|
Ø25 (ML25H0219A)
Ø30 (ML30H0219A)
Ø32 (ML32H0219A)
|
Ø25.4 (ML25.4H0219A)
Ø31.75 (ML31.75H0219A)
|
Ø38.1(ML38.1H0219A)
Ø40 (ML40H0219A)
Ø50 (ML50H0219A)
|
|
Temperature (°C )
|
0~250
|
|
Heating Power (W)
|
1600
|
2400
|
|
Total Power (W)
|
2000
|
2770
|
|
Sample Pressure
|
110-450 kg/cm2 (1565-6400 psi/ 107-441 Bar)
|
|
Max. sample pressure in the cylinder depends on the mount size.
|
|
Please inform us in advance if special demands are required.
|
|
Heating Time (s)
|
Max. 3600 (60 mins)
|
|
Cooling Time (s)
|
Max. 1800 (30 mins)
|
|
Memory Mode (set)
|
40
(Heating temperature, heating time, and cooling time )
|
|
Machine Dimension
WxDxH (mm)
|
540x560x625
|
|
Machine Weight (kg)
|
70
|
71
|
|
Power Supply (V)
|
AC 220V 1Ø
|
|
|
|
|
|
|
|
