We've compiled a table to show the differences between the types of scopes mentioned on this page. The example products are all compact, 4-channel, USB PicoScopes.


	Real-time scope	SXRTO	Sampling scope
Model	PicoScope 6407	PicoScope 9404-05	PicoScope 9300 Series
Analog bandwidth	1 GHz	5 GHz	20 GHz
Real-time sampling?	1 GS/s	500 MS/s	1 MS/s
Sequential equivalent-time sampling?	No	No	15 TS/s
Random equivalent-time sampling?	100 GS/s	1 TS/s	250 MS/s
Trigger on input channel?	Yes	Yes	No – requires external clock or internal clock recovery option
Pretrigger capture?	Yes	Yes	No
Vertical resolution	8 bits	12 bits	16 bits
