| Electrical Requirements |
3 x 400V/N/PE, 50 Hz |
| Number of Lamps |
1, 2, or 3 UV lamps |
| Lamp Power |
2000 W per bulb |
| Intensity (UVA) |
800 mW/cm2 (typical Intensity new bulb at 60 mm distance)* |
| Vertical Clearance |
Adjustable 60-100 mm |
| Dimensions (W x L x H) |
1,100 mm x 1,000 mm x 1,200 mm |
| Working Height (Floor to Belt) |
900 mm on wheel kit or 900 – 950 mm with adjustable screws |
| Control |
Compact PLC |
| Belt |
Belt Material |
Teflon®-coated fiberglass |
| Belt Width |
220 mm |
| Belt Speed |
Adjustable from 0.5-12 m/min |
| Bulbs |
Metal Halide (Fe) – Standard
Mercury (Hg)
Gallium (Ga)
|
| Air Exhaust |
500 m³/h |
